UCF209-28, 4-Bolt Flange Mounted Ball Bearing, 1.75" Bore (ID), Insert Bearing: UC209-28, Housing: F204

UCF209-28, 4-Bolt Flange Mounted Ball Bearing, 1.75" Bore (ID), Insert Bearing: UC209-28, Housing: F204

UCF209-28

$27.24 USD
$27.24 USD
Sale Sold out
Shipping calculated at checkout.

4-Bolt Flange Mounted Unit Ball Bearing

The UC series 4-bolt square flange mounted ball bearings provide reliable shaft support for industrial machinery, agricultural equipment, conveyors, and material handling systems. Designed with a square flange housing and secure locking insert bearing, these units ensure stable mounting and long service life.

Part Number UCF209-28
Shaft Bore (ID) 1.75 in | 44.45 mm
Height 2.055 in | 52.2 mm
Length 5.394 in | 137 mm
Bolt to Bolt Spacing 4.134 in | 105 mm


Applications

  • Conveyor systems
  • Agricultural machinery
  • Material handling
  • General industrial machinery
